For the installation of flat-screen TVs with a screen size from 25 to 94 cm (10 to 37) , an Extremely flat profile allows modern and space-saving interior design , Easy-Fix system for simple and fully adjustable orientation of your TV , Integrated spirit level for fast and easy mounting,Especially suited for ultra-flat televisions, allows optimal positioning of the flat screen in every room , Supports all VESA standards up to 200 x 200 ,-20° continuous tilt
For the installation of flat screen TVs with a screen size from 48 to 94 cm (19″ to 37″)Especially suited for ultra flat televisions, allows optimal positioning of the flat panel display in any roomSupports all VESA standards up to 200 x 200Continuous -20° tilt
ColourBlackProduct DivisionHiFi, TV & Home CinemaShade of colourBlackQualityQuality3 StarsPhysical PropertiesHole Size AttachmentUp to M8MaterialSteel PlateMaximum Load Capacity25 kgModelTVNumber of Joints0Projection maximum5.2 cmProjection minimum5.2 cmRotation0 °Special FeatureSpirit level integratedSwivel Range0 °Tilt +/-0 / 20 °Size & WeightExternal Dimension (Height)30.5 cmExternal Dimension (Width)32.5 cmMounting Plate (Length)28 cmMounting Plate (Width)13.9 cmScreen Dimensions48 cm (19″), 50,8 cm (20″), 56 cm (22″), 58 cm (23″), 61 cm (24″), 66 cm (26″), 71 cm (28″), 74 cm (29″), 76 cm (30″), 80 cm (32″), 84 cm (33″), 86 cm (34″), 89 cm (35″), 91 cm (36″), 94 cm (37″)VESA (from-to)50×50 – 200x200VESA Standard50 x 50, 75 x 100, 75 x 75, 100 x 100, 100 x 200, 200 x 100, 200 x 200Field of ApplicationRecommended Maximum Screen Size94 cm (37″)Recommended Minimum Screen Size48 cm (19″)Recommended Screen Size48 – 94 cm (19″ – 37″)Suitable forTVVersionTilting
